PPC-C168615.6-inch Raspberry Pi industrial web panel
The PPC-C1686 is a 15.6-inch Raspberry Pi-based web panel designed for industrial control and human-machine interface applications. Its full-HD multi-touch display, dual network ports, and front-panel IP65 protection suit connected equipment and operator stations.
Highlights
- Broadcom BCM2712, quad core Cortex-A76 (ARM v8) 64-bit SoC @ 2.4GHz
- up to 16GB LPDDR4 RAM and 64GB eMMC
- Dual network ports
- Support 2.4GHz & 5GHz Wi-Fi, Bluetooth and 4G wireless mode
- 12V~24V wide voltage power input, TVS transient voltage and reverse protection
Certifications
Description
The PPC-C1686 is a 15.6-inch Raspberry Pi-based web panel designed for industrial control and human-machine interface applications. Its full-HD multi-touch display, dual network ports, and front-panel IP65 protection suit connected equipment and operator stations.
Powered by the Broadcom BCM2712 quad-core Cortex-A76 SoC, it supports up to 16GB LPDDR4X memory, eMMC and M.2 SATA storage, 4K HDMI output, multiple serial interfaces, dual-band Wi-Fi, Bluetooth, and optional 4G connectivity. A 12–24V protected DC input and VESA or panel mounting support industrial integration.
