PPC-C161115.6-inch modular industrial panel PC
The PPC-C1611 is a 15.6-inch industrial panel PC designed for industrial control and connected HMI applications. Its modular host-and-display construction supports easier assembly and service, while front-panel IP65 protection and AG/AF surface coating suit demanding installations.
Highlights
- 15.6" LED backlight display (1920x1080 resolution)
- Intel® Alder Lake-U processor
- Front panel IP65
- Surface coating for AG/AF
- 5G module with antenna
- RS232/RS422/RS485 setting by BIOS
- Remote power switch
- Strong expandability for RS232 or CAN&DIO or POE
- DC 12~36V wide voltage input, support RVP/SCP/OVP/OCP
- Modular design of the host and display for easy assembly and disassembly via socket connection
Certifications
Description
The PPC-C1611 is a 15.6-inch industrial panel PC designed for industrial control and connected HMI applications. Its modular host-and-display construction supports easier assembly and service, while front-panel IP65 protection and AG/AF surface coating suit demanding installations.
Built on Intel Alder Lake-U processors, it combines DDR5 memory, dual storage interfaces, multi-touch PCAP, four LAN ports, flexible serial communications, and optional 4G/5G, Wi-Fi, Bluetooth, CAN, DIO, and PoE expansion. A 12–36V DC input and support for Windows and Linux broaden deployment flexibility.
