NPC-321Intel Atom/Celeron · Twin Lake/Alder Lake-N · 2×HDMI+1×DP (Type-C)
The NPC-321 is a compact Alder Lake-N box PC designed for digital signage, desktop computing, and space-constrained commercial deployments. Its low-power Intel platform supports three simultaneous displays for flexible multi-screen installations.
Highlights
- Intel Alder Lake-N low-power processor
- Support three displays, 2*HDMI supports 4K@60Hz, Type-C supports 4K@60Hz
- M.2 2280M Key is compatible with SATA and NVMe
- It features high-speed USB interfaces, including 2*USB3.2 Gen2 Type-A and 2*USB3.2 Gen2 Type-C
- Supports Digital MIC, enabling sound input without the need for an external microphone
Certifications
Description
The NPC-321 is a compact Alder Lake-N box PC designed for digital signage, desktop computing, and space-constrained commercial deployments. Its low-power Intel platform supports three simultaneous displays for flexible multi-screen installations.
The system combines DDR4 memory, M.2 NVMe/SATA storage, dual HDMI and USB Type-C display connectivity, high-speed USB, Gigabit Ethernet, digital microphone input, and optional Wi-Fi and Bluetooth connectivity.
Specifications
Computing
Processor
Intel N95 or N100, TDP 15W
Memory
1 x SO-DIMM, DDR4 3200MHz, Max. 16GB
Storage
1 x M.2 M Key 2280 NVMe/SATA SSD
I/O & Connectivity
Display
2 x HDMI, support 4K@60Hz, 1 x Type-C, support 4K@60Hz
USB
2 x USB3.2 Gen2 Type A, 1 x Type-C (10Gbps, 5V-3A and PD-in), 1 x Type-C (10Gbps), 2 x USB2.0 Type A
LAN
1 x RJ45, 10/100/1000Mbps
Audio
1 x Headphone, 3.5mm, 1 x Digital MIC
Expansion
1 x M.2 E Key 2230 (for WiFi & Bluetooth)
Mechanical & Power
Power
12~19V, 2.5/5.5 DC-in
Environmental
Operating Temperature
-5~45℃ (23~113℉)
Storage Temperature
-20~70℃ (-4~158℉)
Relative Humidity
10%~90% (non-condensing)
Vibration
Operating random vibration test 5~500Hz, 1Grms @with SSD, follows IEC 60068-2-64)
Shock
Operating 10G peak acceleration (11ms duration), follows IEC 60068-2-27)
Certifications & Software
EMC
CE FCC
OS Support
Windows 11, Linux
