NPC-221Intel Core Ultra (Series 1/2) · Meteor Lake/Arrow Lake · 2×HDMI+2×DP (Type-C) · vPRO optional
The NPC-221 is positioned as a compact AI-ready mini PC for multi-display and space-constrained deployments, with four simultaneous 4K display connections, Wi-Fi 6 capability, and quiet operation.
Highlights
- Intel® Core™ Ultra 5 Processor 125H
- Quad 4K Displays : 2 x HDMI 4K + 2 x Type-C 4K
- WIFI6 Wireless network
- Dual Channel SoDIMM DDR5 Max. 32GB
- 1 x M.2 M key 2280 NVMe/SATA(PCIe x4 Gen-4)
- Up to 11 TOPS AI-Optimized
- Maximum noise: 28 dBA (at the 30 cm air outlet)
Certifications
Description
The NPC-221 is positioned as a compact AI-ready mini PC for multi-display and space-constrained deployments, with four simultaneous 4K display connections, Wi-Fi 6 capability, and quiet operation.
Its platform supports Intel Core Ultra processors, dual-channel DDR5 memory up to 32GB, M.2 NVMe/SATA storage, and up to 11 TOPS of AI performance. Six USB ports, 2.5GbE networking, TPM 2.0, programmable watchdog support, and a compact 120 x 120 x 41.2mm chassis round out its deployment capabilities.
Specifications
Computing
Processor
Intel® Core™ Ultra 5 Processor 125H
Memory
2 x SO-DIMM, DDR5, Max. 32GB
Storage
1 x M.2 M Key 2280 NVMe/SATA(PCIe x4 Gen4)
AI Performance
Up to 11 TOPS AI-Optimized
TPM
TPM 2.0
Watchdog
1~255 levels programmable
I/O & Connectivity
Display
2 x HDMI 4K@60Hz, 2 x Type-C 4K@60Hz
USB
Front: 2 x USB3.2 Gen2 Type-A, 1 x Type-C(USB3.2 Gen2,4K@60Hz,PD-out 5V-3A); Rear: 2 x USB2.0 Type-A, 1 x Type-C(USB3.2 Gen1,4K@60Hz,PD-in 20V-5A PD-out 5V-3A)
LAN
1 x 10/100/1000M/2.5Gbps RJ-45
Audio
1 x Line-out & Mic-in 2 In 1; 2 x Build-in D-MIC
Expansion
1 x M.2 E Key 2230 (for WiFi & Bluetooth)
Mechanical & Power
Power
DC 19V; CPU TDP 28W
Dimensions
120x120x41.2mm (4.7x4.7x1.6in)
Weight
0.56kg (1.26lb)
Environmental
Operating Temperature
-5~45℃ (32~122℉)
Storage Temperature
-20~70℃ (-4~140℉)
Relative Humidity
10%~95% non-condensing
Vibration
Operating random vibration test 5~500Hz, 1Grms @with SSD, follows IEC 60068-2-64
Shock
Operating 10G peak acceleration (11ms duration), follows IEC 60068-2-27
Certifications & Software
EMC
CE/FCC Class A
OS Support
Windows10, Windows11, Linux
