MPC-311Intel Atom/Celeron · Elkhart Lake · HDMI+DP · Fanless · 4G optional
The MPC-311 is a compact, low-power Intel media player for digital signage and other multi-display deployments. Its HDMI and DisplayPort outputs each support 4K at 60 Hz for flexible dual-screen installations.
Highlights
- Intel low power processor J6412 or N6415
- Dual Channel LPDDR4X Max. 8 GB
- Dual displays, HDMI & DP both support 4K@60Hz
- M.2 2280 M Key is compatible with SATA and NVMe
- Multiple USB interfaces, three USB3.0, five USB2.0
- There are multiple network connection methods, including 1000Mbps Ethernet port, WiFi and 4G/5G options
Certifications
Description
The MPC-311 is a compact, low-power Intel media player for digital signage and other multi-display deployments. Its HDMI and DisplayPort outputs each support 4K at 60 Hz for flexible dual-screen installations.
It supports Intel J6412 or N6415 processors, up to 8GB of dual-channel LPDDR4X memory, and M.2 2280 NVMe or SATA storage. Eight USB ports, Gigabit Ethernet, an RS232 COM port, audio, optional WiFi and Bluetooth, and optional 4G/5G connectivity provide broad peripheral and network support.
Specifications
Computing
Processor
Intel Processor J6412/N6415,TDP 6~10W
Memory
Dual Channel LPDDR4X Max. 8GB
Storage
1 x M.2 M Key 2280 NVMe/SATA SSD
TPM
TPM2.0
Watchdog
Support
I/O & Connectivity
Display
1 x HDMI, support 4K@60Hz, 1 x DP, support 4K@60Hz
USB
3 x USB3.0 Type A, 5 x USB2.0 Type A
LAN
1 x RJ45, 10/100/1000Mbps
COM
1 x COM, RS232
Audio
1 x Line-out, 1 x Mic-in
Expansion
1 x M.2 E Key 2230 (for WiFi & Bluetooth), 1 x M.2 B Key 3040/3050 (for 4G/5G)
Mechanical & Power
Power
12V, 2.5/5.5 DC-in
Dimensions
151.8x127.8x32.5mm (6.0x5.0x1.3 in)
Weight
0.8kg
Environmental
Operating Temperature
-5~45℃ (23~113℉)
Storage Temperature
-20~70℃ (-4~158 ℉)
Relative Humidity
10%~90% (non-condensing)
Vibration
Operating random vibration test 5~500Hz, 1Grms @with SSD, follows IEC 60068-2-64)
Shock
Operating 10G peak acceleration (11ms duration), follows IEC 60068-2-27)
Certifications & Software
EMC
CE FCC
OS Support
Windows 11, Linux
