MPC-111Intel Gen12 Core · Alder Lake · 2×HDMI+DP+Type-C · Fanless · Super Slim/vPRO optional
The MPC-111 is a compact media player designed for multi-display digital signage and other visual-content deployments. Its Intel Alder Lake-U or Raptor Lake-U platform supports four simultaneous display outputs, including DisplayPort output up to 8K@60Hz.
Highlights
- Intel Alder Lake-U or Raptor Lake-U processors
- Supports DDR4 dual-channel memory, Max. 32GB
- Support quad display, DP supports 8K@60Hz, 2 x HDMI supports 4K@60Hz, HDMI 1 optional HDMI CEC, Type-C supports 4K@60Hz
- Two M.2 2280 M Key interfaces are provided, respectively supporting the NVMe protocol and the SATA protocol
- Dual RJ45 network ports, supporting up to 2.5Gbps
Certifications
Description
The MPC-111 is a compact media player designed for multi-display digital signage and other visual-content deployments. Its Intel Alder Lake-U or Raptor Lake-U platform supports four simultaneous display outputs, including DisplayPort output up to 8K@60Hz.
The system supports up to 32GB of dual-channel DDR4 memory, separate NVMe and SATA M.2 storage interfaces, dual RJ45 networking with an optional 2.5Gbps rate, and Windows 10/11 or Linux. Its connectivity includes HDMI, DisplayPort, USB Type-C, USB Type-A, dual COM, audio, and an M.2 E Key interface for WiFi and Bluetooth.
